| Specification Parameter | Details / Range |
|---|---|
| Model Number | NMA-11 Monitor Mount |
| Compatible Screen Size | 34″ – 57″ Ultrawide & Curved Screens |
| Weight Capacity | 10 – 20 kg (22 – 44 lbs) |
| Vertical Lift Range | 545 mm |
| Pole Height / Diameter | 400 mm / Ø35 mm |
| Tilt Angle | +80° ~ -5° |
| Swivel Range | ±90° |
| Screen Rotation (Pivot) | ±90° |
| VESA Compatibility | 75 x 75 mm / 100 x 100 mm |
| Desktop Thickness Range | 20 – 60 mm (0.78″ – 2.36″) |
| Installation Methods | C-Clamp & Grommet Mount Included |
| Material & Finish | Aluminum Alloy, High-Grade Steel, Matte Black Powder Coating |
| Applications | Corporate Offices, Commercial Workstations, Financial Trading Desks, Gaming Setups |
NMA-11 Pole-Mounted Heavy-Duty Gas Spring Monitor Mount for 34″-57″ Curved & Ultrawide Screens
Hero Bullet Points
-
Ultra-Heavy Weight Support: Monitor Mount Engineered to handle large 34″-57″ ultrawide and curved monitors weighing up to 20kg (44 lbs) with rock-solid stability.
-
Tall Pole & Gas Spring Hybrid: Features a 400mm vertical pole combined with a smooth counterbalanced gas spring arm for extended height adjustability and effortless positioning.
-
Full-Motion Ergonomic Flexibility: +80°/-5° tilt, ±90° swivel, ±90° pivot, and a total vertical lift range of 545mm allow instant optimal viewing angles.
-
Dual Installation Options: Supports both heavy-duty C-clamp and grommet desk mounting with integrated cable management for clean, professional commercial setups.
Overview & Features
Heavy-Duty Architecture for Next-Gen Ultrawide Displays
Monitor Mount Designed specifically to meet the demands of modern high-performance workstations, the Monitor Mount accommodates heavy-duty displays ranging from 34 to 57 inches. Its reinforced internal gas spring mechanism easily supports loads between 10kg and 20kg, providing effortless floating height adjustment without screen sagging or drifting.
Tall-Pole Elevation with Precision Free-Stop Positioning
The integrated 400mm center pole extends the vertical range up to 545mm, giving users complete control over monitor height and focal distance. Whether utilized in standing desk configurations or multi-tier workstation setups, the free-stop positioning system allows precise micro-adjustments with zero strain.
Built for Commercial Spaces & Modern Workspaces
Crafted from premium aluminum alloy and high-grade steel, the Monitor Mount features internal cable routing channels to conceal wires and preserve a minimal desktop aesthetic. Its versatile C-clamp and grommet mounting options accommodate desk thicknesses from 20mm to 60mm, making it an ideal OEM/ODM solution for corporate offices, financial trading floors, executive suites, and gaming workstation setups.
Technical Specifications Table
| Specification Parameter | Details / Range |
|---|---|
| Model Number | NMA-11 |
| Compatible Screen Size | 34″ – 57″ Ultrawide & Curved Screens |
| Weight Capacity | 10 – 20 kg (22 – 44 lbs) |
| Vertical Lift Range | 545 mm |
| Pole Height / Diameter | 400 mm / Ø35 mm |
| Tilt Angle | +80° ~ -5° |
| Swivel Range | ±90° |
| Screen Rotation (Pivot) | ±90° |
| VESA Compatibility | 75 x 75 mm / 100 x 100 mm |
| Desktop Thickness Range | 20 – 60 mm (0.78″ – 2.36″) |
| Installation Methods | C-Clamp & Grommet Mount Included |
| Material & Finish | Aluminum Alloy, High-Grade Steel, Matte Black Powder Coating |
| Applications | Corporate Offices, Commercial Workstations, Financial Trading Desks, Gaming Setups |
